Know more about AMPSEAL 16 series

435d7945302bfac8af19df77652c177b market broadband

AMPSEAL 16 receptacle style housings for pin contacts with integral primary latch reinforcement and CPA for secure locking. These AMPSEAL 16 automotive connectors have colour coding and physical keying to prevent miss-mating. These environmentally sealed wire-to-wire and wire-to-device connectors are available in 2, 3, 4, 6, 8, and 12-way arrangements.

The AMPSEAL 16 series offer customers both male and female components and include either Thermoplastic or Glass Fibre Reinforced PBT housing material. These products have a cable mount mounting type with it’s connectors acting as a crimp termination method, this brings ease of use to customers as well as improved quality.

Features and Benefits

• Number of contacts: 2, 3, 4, 6, 8 and 12 cavity arrangements.

• Keyed / Polarized, prevents miss-mating. Unclipped contacts, no damaged tangs or tangled contacts.

• Accepts contact size HDSF 16 (up to 13 amps)

wire range 14-20 AWG (2.50-0.50 mm2)

• Cable exit angle: 180°

• Operating temperature range: -40°C to +125°C

• Pitch 4.5 mm

• Current: Up to 13 amps

• Rectangular, thermoplastic housing. Resistant to a wide range of chemicals. Sleeved assembly for contact beam protection provides 50 durability cycles

• Integrated latch for mating

• Integrated Primary Latch Reinforcement (PLR) confirms contact alignment and retention

• Available accessories: Back shells, mounting clips. Attachment feature on pin housing provides connector clip mounting. Integral CPA protects against accidental unlocking.

• In-line mount. Integral PLR provides primary latch reinforcement with no additional assembly. Sealing of interface and wires provides for environmental integrity. Sleeved assembly for contact beam protection provides 50 durability cycles

So what vehicles are this component made for?

TE Connectivity’s AMPSEAL 16 connectors are targeted for off-road, heavy-duty industrial, recreational and agricultural applications. This wire-to-wire and wire-to-device connector line was designed to meet the rigorous demands of an industry that requires the highest standards in performance. AMPSEAL 16 receptacle and pin housings offer a one-piece approach and come fully assembled. These connectors offer rugged reliability, easy use, and help prevent moisture and dirt from contaminating connections.
